Backsplash downdraft table

BACKSPLASH TABLE FOR SUCTION OF SOLVENTS

Because local exhaust ventilation must always be A priority when dangerous products are emitted, STIVENT INDUSTRIE® has developed its range of backsplash downdraft tables.

Dust, fumes and harmful vapours are thus captured as close as possible to their source of emission and sucked before they reach the respiratory tract of operators.

The backsplash downdraft table is used in particular for cleaning, gluing, mixing, degreasing, dissection and penetrant testing operations.

It produces a low noise level, it is less than 70 dB (measured at the work surface).

As standard, it is equipped with removable cheeks, a laminated wood worktop, removable shelf(s), a removable cover and adjustable feet. It is also possible to add a fan (on the table or next to it).

For treatments in explosive environments, the equipment meets the ATEX standard.

All our tables are customisable and/or scalable according to your needs and technical constraints. Contact us on (+33) 05 49 50 41 91 or via our contact form. Together, we'll find a solution.



> BACKSPLASH DOWNDRAFT TABLE - DAF 1200



> BACKSPLASH DOWNDRAFT TABLE - DAF 2000



CARACTÉRISTIQUES DE LA GAMME

Ergonomic, the backsplash table allows you to work in a standing or sitting position.

It is available in 4 sizes:

  • Overall dimensions in mm (D x W x H): 800 x 800 x 500
  • Power kW: variable
  • Average minimum speed m/s: 0.5
  • Total minimum flow m3/h: 720



  • Overall dimensions in mm (D x W x H): 800 x 1200 x 500
  • Power kW: variable
  • Average minimum speed m/s: 0,5
  • Total minimum flow m3/h: 1080



  • Overall dimensions in mm (D x W x H): 800 x 1600 x 500
  • Power kW: variable
  • Average minimum speed m/s: 0,5
  • Total minimum flow m3/h: 1440



  • Overall dimensions in mm (D x W x H): 800 x 2000 x 500
  • Power kW: variable
  • Average minimum speed m/s: 0,5
  • Total minimum flow m3/h: 1800
